Small and Powerful Red Laser Pen 635nm 500mW That Burns

This model is small, strong, and durable. The visibility at 635nm is higher than other common red lasers. Due to size limitations, we cannot achieve more than 500mW for this 635nm laser pen. If you need to make customizations for different wavelengths and powers, please contact us via info@lasersea.com.

Specifications
• Wavelength: 635nm (red)
• Output power: 200mW / 300mW / 500mW
• Laser divergence: < 1.5mRad / < 2.5mRad
• Housing material: stainless steel
• Multi-mode (optional): high power, low power, strobe
• Protection: PCB protection, reverse polarity protection
• Waterproof Rating: IPX4
• Power supply: 1 x 10440 battery
• Operating voltage: DC 3.7V
• Gross weight: 486 g

Tips for Use

How to turn on the laser
Insert the battery with the positive side going in first, then screw on the base cap and press the bottom switch to power the laser.

Multi-mode
The laser starts with the operation mode that was used in the last operation. Press the button halfway to enter the next operating mode. Here is the cycle of 3 unique operating modes in the following order: high power > low power > strobe.

Adjustable focus
This laser pointer has a fully adjustable focus. Please rotate the top of the laser to adjust the beam focus.

Battery protection
Our lasers come with various battery protection: overcharge protection, overcharge protection and reverse polarity protection.

What's in the professional package?
• 1 x 635nm red laser pen
• 1 x Laser safety goggles
• 1 x 10440 rechargeable battery
• 1 x Battery charger
• 1 x Instructions, warranty card
