Product advantages
1) Two engraving methods: spindle and laser module.
2) X/Y/Z axis limit switch function: After the limit switch is installed, when the XYZ axis exceeds the range of the engraving machine, the limit switch will trigger the machine to stop automatically.
3) Simple Assembly - This mini CNC laser engraving machine comes with detailed user manual and assembly instructions. Simply hand-assembled according to the installation instructions, then you can enjoy the delight of using an engraving machine.
4) Emergency stop button: This function can be used when an emergency stop is required during work, which makes the engraving machine safer and more practical.
5) GRBL control board: the GRBL control board can be connected to a computer via a USB interface, featuring dual Y-axis, four-axis drive, and full functionality.
6) PWM/TTL signal control is available, and the power is 0-100% adjustable!
7) Driven by an integrated imported stepping motor with short circuit protection.
8) It uses a fan to force cooling.
9) Off-line identification function: You can insert the off-line module and the computer at the same time, and the off-line will automatically identify whether there is computer control.
10) Optical coupler isolation is added to the spindle drive, so the control board generates less heat, and the spindle speed regulation is more linear and safer.
Specifications
• Frame size: 330x340x240mm
• Working area: 240x180x40mm
• Spindle: 775 spindle motor (12-36V) 24V: 10000r/min
• Spindle chuck: ER11
• Step motor: Fuselage length 34MM, Current 1.33A, 12v.Torque 0.25N/M
• Power supply: 24V 5.6A （110V -240V）
• Software: GRBL controller
• Support system: Windows XP / Win 7 / Win 8 / Win 10
• Drill bits: 3.175 mm diameter (10pcs)
• Construction material: aluminum alloy
• Spindle drive chip: MOSFET (recommendation 12~36V, current: within 10A )
• Spindle PWM speed: support
• Laser engraving: support
• Laser output: 1W / 1.6W / 2.5W / 3W / 5.5W / 7W / 10W / 15W
• Power interface: 5.5-2.5mm DC interface
• Engraving materials: plastic, wood, acrylic, PVC, PCB, soft metals, etc.
Offline controller module:
Without an offline controller module: You need to connect the laser engraving machine to the computer to work
With an offline controller module: The laser engraving machine can work directly. No need to connect to a computer.
Package Contents
1 x DIY 3-Axis CNC Laser Engraver
1 x Laser Module (Optional)
1 x Offline Controller Module (Optional)
1 x GRBL 1.1f Control Board
1 x 775 Spindle Motor
1 x ER11 Collet
1 x Power Supply
10 x CNC Drill Bits
4 x Plate Clamps
3 x Allen Wrenches
1 x 4G USB Flash Drive
1 x English User Manual & GRBL Software |
