Laser Cutting Module

The World's Most Powerful Blue Laser Cutting Module 450nm 20W

For product customizations, please contact us by mail. We will reply to you within 24 hours.

Price: $429.63

Quantity:

Product Details

This model is our most powerful blue laser module, mainly used for engraving and cutting (wood, plastic, and metal). It has 20W ultra-high power, ultra-small laser spot (0.07 x 0.13 mm), 24V working voltage, and PWM modulation. The carving marks are very thin (0.08mm), so you can carve and cut finely with this module. It adopts a uniform compressed spot (LD+FAC+C-Lens) with high brightness, high efficiency, and high definition.

This product is power tested and 8 hours burn-in tested, so you don't have to worry about stability or longevity. If you're looking for the world's most powerful laser module, this will be a perfect choice.

Specifications
• Laser type: dot
• Output wavelength: 450nm / 445nm
• Output power: 18-22W
• Adjustable focus: yes
• Housing material: 6061 aluminum
• Working voltage: DC=24V
• Working current: < 3.2A
• Focal length: 40±1mm
• Focus size: < 0.5mm
• Minimum focal point: 0.07 x 0.13 mm
• The best engraving focal length: 10mm
• Electric power: 69.2W - 76.8W
• Working mode: pulse work
• Optical lens: φ10 / glass
• Fan: 24V / double ball 7500 rpm
• Circuit board: 24V / PWM modulation board
• Useful life: > 10000 hours
• Working temperature: 10℃~+70℃
• Storage temperature: -40℃~+85℃
• Structural dimensions: 66 x 63 x 106 mm
• Circuit board dimensions: 45 x 81mm
• Wire rod: 22# 2P 2.54 terminal reverse wire 120mm
